GALVANNEALED STEEL SHEET METAL

(ZINC-IRON ALLOY COATED SHEET)

Introduction to Galvannealed Steel Sheet

If you're looking for a reliable corossion resistant material for painted products, Wheeling-Nippon Steel's galvannealed steel sheet is an exceptional choice. Featuring a zinc-iron alloy coating, it boasts a remarkably uniform surface, making it perfect for applications that demand superior paint adhesion and long-lasting performance.

Its excellent surface qualities make it an ideal candidate for a variety of painted applications, including signage, corrugated building materials, electrical equipment, and truck utility bodies.

It also provides a consistent surface ideal for excellent formability, weldability, galvanic protection and flatness. The zinc-iron alloy coating is harder than galvanized steel making it more resistant to scratching and manufacturing damage than comparable coated steel products. The combined effect between the paint and the lower overall corrosion rate of the galvannealed coating can extend the life of your product. It is produced to ASTM A653 specifications and is used in various applications, a number of which are listed below.

Key Features of Galvannealed Steel Sheet

Consistent alloy surface
Perfect paintability
Excellent formability and flatness

Galvanneal Sheet Metal | Galvannealed Steel | Road Signs Made with Galvanneal

Galvanneal Sheet Metal | Galvannealed Steel | Galvanneal Steel Filing Cabinet

Galvanneal Sheet Metal | Galvannealed Steel | Galvanneal Steel Garage

Galvannealed Sheet Metal Specifications

Material Thickness

0.014" through 0.130"

Material Width

24" through 61"

ASTM Specification

ASTM A653

Steel Grades

Commercial Steel	Deep Drawing Steel
Extra Deep Drawing Steel	HSLA Steel Grades
Structural Steel Grades	Forming Steel

Coating Weight

A25

A40

A60

(UL Coating Weights available. Please inquire)

Coil Weight

10,000 lbs. minimum through 55,000 lbs. maximum

Coil ID

20" and 24"

After Treatment
(upon request)

Chemical Treatment (RoHS Compliant Available)

Oiling

Acrylic (RoHS Compliant, Please Inquire)

Stenciling

Galvanneal Sheet Metal | Galvannealed Steel | Galvanneal Steel for Tank on Truck

Galvannealed Steel Sheet Applications

Galvannealed sheet metal can be used in a wide array of applications, in construction, maintenance, signage and more. Some of the most common applications for galvannealed steel sheets include:

Automotive
Highway Signage
Partitions
Electrical Equipment
Doors
Door Frames

Garage Doors
Molding
Trailers
Cabinets

... and many more.

If you're not sure which of our products would make the best fit for your specific application, contact our sales team and let us help you choose the ideal coated steel for your task. From painted signs to the very buildings they hang on, WHEELING-NIPPON STEEL is the coated steel supplier that provides what you need, when you need it.
